IMAGINiT Utilities for Civil3D

Productivity and management tools for Civil3D.

Overview

Imaginit Utilities for Civil3D expands the functionality of Civil3D with a set of features and functionality to help you improve productivity.

Distance Between Pipes Crossing

Calculate the approximate distance between two pipes and add labels.

Quick Edit for Pipes

Quickly change the invert or slope/grade of pipes in a gravity network. Enhancements in 2021 allow you to work in new ways with glyph/scale, and profile view support.

Pipe Invert Adjustment

Easily set a pipe invert at the beginning and endpoint of a run and calculate a consistent slope between the structures.

Polyline from Feature Line

Extract a polyline (including curves) from a 3D feature line.

Import Maps

By utilizing data from Google Maps or Bing, you can import color, georeferenced images as well as data for tin creation and terrain surfaces within Civil 3D.

Pipe Elevation Adjustment

Lets you raise or lower a set of pipe segments or an entire run.

Pipe Grade Adjustment

Makes it easier to re-adjust the grade or slope of a series of pipes. The tool can hold the invert, centerline, or crown as well as deal with drops in structures.

Multi-Part Swap

Change the Family and Size of many pipes or structures on the network – all with one click.

AutoOffset

A must-have if you work with linear design along roads (strip topo) and have a need to identify and label significant topography points (trees, structures, markers, etc.) from survey data points. The utility calculates and labels each respective point’s information in the drawing, parallel to the selected alignment, and all in a format you design.

Style Renamer

Allows you to perform a batch re-naming of all kinds of styles.

Create Offset Points

Create offset points along a feature line with a specified offset. The perfect tool for creating stakeout points for a survey crew or in grading workflows.

Profile from COGO Points

Quickly creates a profile from specified points. No surface required and we take care of creating the alignment.

Point Station and Offset Report

This tool generates a report of points along an alignment based on parameters you define; this information can then be exported to HTML or Excel for further analysis and use. All point parameters are available (number, name, northing, easting elevation, etc.) as well as station value and offset distance from an alignment.

KML/KMZ Import

Brings geometry from Google Earth/Google Maps into your drawing.

Utilities for Civil3D

Productivity tools for Civil3D
$ 499 Standalone Perpetual Licence
  • Current Release
  • Includes updates and support
  • Standalone

Utilities for Civil3D

Productivity tools for Civil3D
$ 1,499 Network Perpetual Licence
  • Current Release
  • Includes updates and support
  • Network

Utilities for Civil3D

Productivity tools for Civil3D
Trial Get a free 14 day Trial
  • Current Release
  • Includes updates and support
  • Standalone

Download Brochures

Click on the images below to download a PDF brochure

PDF Logo small Moving at the Speed of Business
Utilities for Civil3D

Contact Us

If you would to discuss IMAGINiT Utilities for Civil3D, please contact us by calling on 1800 490 514, by filling out the form or clicking the live chat in the bottom right-hand corner.
