Inventor CAM and Nesting Software

A set of integrated fabrication tools for Inventor Professional found within the Product Design & Manufacturing Collection
Autodesk Inventor CAM

Inventor CAM

Inventor Nesting

Inventor CAM

Autodesk® Inventor® CAM software is included in the Product Design & Manufacturing Collection and integrated within Inventor Professional for 2.5-axis to 5-axis milling, turning, and mill-turn machining.

  • Advanced roughing system that efficiently removes high material volumes which minimises your CNC machines wear and tear on tooling
  • Generates G-Code for CNC Machines

4- and 5-axis milling

Simultaneous 4- and 5-axis features for machining complex models include tilt, multi-axis contour, and swarf.

Turning and mill-turn

Improve productivity with traditional turning, facing, grooving, and boring functions. Includes support for live tooling mill-turning.

Inventor CAM Features and Functions

Drill Toolpaths

These are the types of drilling motion that can be performed:

  • Drilling – G81 style drilling with rapid out.
  • Counterboring – G82 style drilling with dwell at bottom and rapid out.
  • Chip breaking – Chip breaking with pecking and partial retracts between pecks.
  • Deep drilling – Deep drilling with pecking and full retract between pecks.
  • Guided deep drilling – gun drilling – Deep drilling that produces a very round hole with a precision diameter. Very useful for deep, straight holes in a variety of materials.
  • Tapping – Tapping (G84/G74). Synchronous spindle speed and feed.
  • Tapping with chip breaking – Tapping with chip breaking.
  • Break through – Allows for reduced feed and speed before breaking through a hole.
  • Reaming – Reaming (G85 style) with feed out.
  • Boring – Boring with dwell at bottom and feed out.
  • Stop boring – Boring (G86 style) with spindle stop at the bottom and rapid out.
  • Fine boring – Fine boring with shift away from the hole side.
  • Back-boring – Boring from the back.
  • Circular pocket milling – Circular pocket milling.
  • Bore milling – Bore milling.
  • Thread milling – Thread milling.
  • Probe – Used to measure a feature on the part with a probe tool, or use macros from the machine to define the WCS. Needs special handling in the post processors depending on the machine.
Coolant

Select the type of coolant used with the machine tool. Not all types will work with all machine postprocessors.

what is inventor cam 04 thumb 1172x660 1 Moving at the Speed of Business
Feed & Speed

Spindle and Feedrate cutting parameters.

  • Spindle Speed – The rotational speed of the spindle expressed in Rotations Per Minute (RPM)
  • Surface Speed – The speed which the material moves past the cutting edge of the tool (SFM or m/min)
  • Plunge Feedrate – The drilling feedrate when plunging into stock
  • Feed per Revolution – The plunge feedrate expressed as the feed per revolution
  • Retract Feedrate – Feed used when retracting, but not using rapid moves (G0)
what is inventor cam 02 thumb 1172x660 1 Moving at the Speed of Business
3D Milling
what is inventor cam 05 thumb 1172x660 1 Moving at the Speed of Business
Probing Cycle Reference
  • Single axis probing
  • Corner probing
  • Block center probing
  • Rectangular cavity center probing
  • Circular boss center probing
  • Circular hole center probing
  • Rectangular and Circular cavity with Islands
  • Between 2 walls/faces
Multi-Axis Milling Functionality
  • Single axis probing
  • Corner probing
  • Block center probing
  • Rectangular cavity center probing
  • Circular boss center probing
  • Circular hole center probing
  • Rectangular and Circular cavity with Islands
  • Between 2 walls/faces

Learn More about the Product Design & Manufacturing Collection

Design Consulting Product Design Manufacturing Collection Moving at the Speed of Business
Autodesk Inventor Nesting

Inventor Nesting

Inventor® Nesting software which is integrated within Inventor Professional turns sheet metal parts into nesting tables.

By optimising the nest table, companies reduce raw material costs and can compare nesting studies to better understand cost and choose the right nesting study.

  • Have multiple material and packaging options by generating multiple sheet nests in a single study

  • Maximise job profitability by comparing costs and the efficiency associated with nesting studies variations.

  • Ensure consistent grain direction on all parts to prevent cracking in subsequent bending operations by specifying allowable orientations.

automated true shape nesting large 1920x1080 1 Moving at the Speed of Business

Automated true-shape nesting

Generate multiple sheet nests to reduce raw material waste. Optimize the use of materials in flat cutting operations.

Smooth workflows for creating cutting paths

Create 3D models of a nest and generate cutting paths with Inventor CAM, or export DXF files. Use DXF files in AutoCAD and other toolpath-making software.

smooth workflows for creating cutting paths thumb 1172x660 1 Moving at the Speed of Business

Inventor Nesting Features and Functions

  • Supports Inventor ipt, iam and AutoCAD dwg or dxf files.
  • Setup Nest and Quantities
  • Set Up Shapes
  • Set Up Packaging
  • Adjust Parameters and Performance
  • Create the Nesting Study
  • Calculate Nests
  • Compare Nests
  • Change Shape Priority and Orientation
  • Edit Shape Properties
  • Nest Reports
  • Generate a 3D Model
  • Import and Export Data to CSV or XML
  • Process Material Library
  • Set Nesting Parameters
  • Set Composite Properties
GUID 3F242E77 4CC5 4580 A783 64189795701B Moving at the Speed of Business

Learn More about the Product Design & Manufacturing Collection

Design Consulting Product Design Manufacturing Collection Moving at the Speed of Business

Get a CNC Post for Inventor or Fusion 360

what is inventor cam 05 thumb 1172x660 1 Moving at the Speed of Business

Learn more about Autodesk Fabrication Products

Autodesk has various fabrication software products for manufacturing, architectural construction, HVAC and structural steel applications

PDM Collection Add-Ons

Check out these programs and plug-ins to boost productivity even further.
Enterprise data management.
Additive manufacturing simulation and optimisation.
Cloud Collaboration with Fusion 360 Team Participant
Machine tool probing software for on machine verification and inspection.
Computational Fluid Dynamic software to simulate loads, air and fluid flows.
Injection mold simulation software
